• Precision lathe
• Toolmaking accurac according to DIN 8605
• centre height: 167 mm
• Centre width: 1000 mm

• Lathe

• Travel (X/Y/Z): 750x500x600 mm

• Travel X/Y/Z: 300x250x250 mm
• max. workpiece size W/D/H: 770x290x400 mm

• Oil bath machine: Ra 0.05 µm
• Position accuracy: < ± 1 µm
• Surface finish: Ra 0.04 µm
• Roundness: < 1 µm
• Geometry accuracy: < + 1 µm
• Travel X/Y/Z: 300x200x180 mm
• max. workpiece size W/D/H: 620x610x100 mm

• Possible wire diameters: 0.1–0.3 mm
• Travel X/Y/Z: 600x400x310 mm
• max. Workpiece size W/D/H: 1050x820x305 mm

• Travel (X/Y/Z): 400x300x220 mm

• Travel (X/Y/Z): 650x450x350 mm
• max. Workpiece size W/D/H: 1040x760x350 mm
• min. command step (X/Y/Z/U/V): 0.1 μm
• min. axis resolution: 0.1 μm

• Travel (X/Y/Z): 400x300x300 mm
• max. Workpiece size W/D/H: 850x640x250 mm
• min. command step (X/Y/Z/U/V): 0.1 μm
• min. axis resolution: 0.1 μm

• Travels (X/Y/Z): 500x350x300 mm

• 5-axis milling machine
• Max. Travel: X/Y/Z: 700x420x380 mm
• Max. Table weight: 400 kg
• Table dimensions: 840x420 mm
• Swivel rotary table for 5-axis simultaneous machining
• Large swivel range of the A-axis: -100°/+120
• Table diameter 200 mm for workpieces up to 100 kg

• max. Travel X/Y/Z: 700x420x380 mm
• max. Table load: 400 kg
• Table length: 840 mm
• Table width: 420 mm

• max. Travel X/Y/Z: 500x450x400 mm
• max. table load: 300 kg
• Table diameter: 630 mm
• 5 axes simultaneous machining with rigid swivel rotary table
• Swivel range of B-axis: -5/ +110°
• Large diameter table bearings for highest precision

5-axis milling machine

3-axis milling

Surface grinding machine

• Table travel: 650x230 mm
• Load: 200 kg
• Table grooves: 17 x 1
• Table speed: 0.3–25 m/min

• Precision surface and profile grinding machine
• Perfect for toolmaking, jigmaking and small batch production
• Hydraulic surface and profile grinding machines
• Cross table design
• Double V-guides lengthwise and crosswise
• LSI control system proven over many years

• max. swing diameter: 220 mm
• max. centre distance: 500 mm
• max. grinding diameter: 200 mm
• max. workpiece weight: 60 kg
• X-axis travel: 203 mm
• Z-axis travel: 640 mm
